    Referencia interna:​ JAM66S30-505/MR

    Descripción del Producto

    Including cable (ca. 120 cm) MC4 EVO2 connector system Stable anodized alu-frame Thermally pre-stressed solar glass High-performance solar cells Version with 11 busbars Glass thickness 3.2 mm
    Battery Connection ac
    Temperature Coefficient Isc 0.045
    Temperature Coefficient Pmpp -0.35
    Temperature Coefficient Uoc -0.275
    Current Shortcircuit isc 14.0
    Nominal Current Impedance 13.11
    Panel Cells Accross 6
    Panel Cells Accross Height 22
    Power Nominal Pmax 505.0
    Panel Cell Depth 182.0
    Panel Cell Type mono
    Panel Connector Type mc4evo
    Panel Frame Type std
    Power Tolerance +5 Wp
    Open Circuit Current Uoc 45,72
    System Maximum Current 1500
    Nominal Current Umpp 38,53
    Product Manufacturer JA Solar
    Factory Reference JAM66S30-505/MR
    Certification 1 IEC/TÜV
    Certification 2 Protection Class 2
    Backsheet Color white
    Frame Color silver
    Panel Cell Length 83.0
    Panel Cable Length 120.0
    Length 2093.0
    Height 30.0
    Depth 1134.0
    Palets per Contener 22
    Units per Contener 792
    Units per Palets 36
    Product Warranty 12
    Product Performance Guaranteed 25
