Meyer Burger Black 390

https://www.autoconsumosolar.es/web/image/product.template/23690/image_1920?unique=8d4cc6c

243,80 € 243.8 EUR 243,80 €

265,00 €

Not Available For Sale

  • Marca

This combination does not exist.

Contact Us
Stock:  10392 Unidades

Términos y condiciones
Garantía de devolución de 30 días
Envío: 2-3 días laborales

Referencia interna:​ 10301299

Battery Connection ac
Temperature Coefficient Isc 0.033
Temperature Coefficient Pmpp -0.259
Temperature Coefficient Uoc -0.234
Current Shortcircuit isc 10.7
Nominal Current Impedance 10.1
Panel Cells Accross 6
Panel Cells Accross Height 20
Power Nominal Pmax 385.0
Panel Cell Depth 166.0
Panel Cell Type hybrid
Panel Connector Type mc4
Panel Frame Type std
Power Tolerance +5 Wp
Open Circuit Current Uoc 44,60
System Maximum Current 1000
Nominal Current Umpp 38,40
Product Manufacturer Meyer Burger (Industries) GmbH
Factory Reference 10301298-10303933-B1
Certification 1 IEC/TÜV
Certification 2 Protection Class 2
Backsheet Color black
Frame Color black
Panel Cell Length 83.0
Panel Cable Length 120.0
Length 1767.0
Width 1041.0
Height 35.0
Depth 1041.0
Palet Weight 650.0
Palet Dimensions 1780x1050x1300
Palets per Contener 28
Units per Contener 840
Units per Palets 30
Product Warranty 25
Product Performance Guaranteed 25

Especificaciones

Marca Meyer Burger
